CAME KRONO KR310D Swing Gate Motor Oman, 230V Kit for 3 m Leaves

Description

The CAME KRONO KR310D, CAME code 001KR310D, is an irreversible right hand 230V swing gate motor with opening and closing limit switch microswitches, for gates with leaves up to 3 metres long and 400 kg. It draws 240 W and 1.1 A, gives 400 to 3000 N of thrust and opens to 90 degrees in 22 seconds. CAME rates it for up to 16 cycles an hour, with an IP54 rating.

Two points come first. The D is the right hand motor, and a double gate may also need the left hand KR310S, so we confirm what your price covers. And CAME does not publish a clear opening angle table, so we measure your pillars before we quote.

CAME KRONO KR310D price in Oman and what is in the kit

Price: OMR 310.000, in stock at our Muscat shop. Installation is quoted separately once we have seen the gate.

A standard double gate kit from our supplier includes two motors, a control board, two TOP 432EE remotes, a receiver, Bluebus photocells, a flashing light, two brackets and a push button. We confirm the exact contents of the KR310D set, and whether it has one right hand and one left hand motor, before you pay.

3 m leaves and 400 kg: is the CAME KRONO KR310D right for your gate

CAME’s limits table pairs a 3 metre leaf with 400 kg, a 2.5 metre leaf with 600 kg and a 2 metre leaf with 800 kg. A shorter leaf can carry more, because it puts less leverage on the arm. We confirm that the limit applies to each leaf, and we ask for the weight and the length of each leaf.

For leaves up to 5 m, CAME makes the KR510 version at 400 kg. We quote it if your gate is longer.

Right hand KR310D and left hand KR310S: which side does each leaf need

A swing gate motor is built for one side. CAME sells the right hand KR310D and the left hand KR310S, and the handedness depends on which way the leaf hinges, seen from the pillar. A double gate usually has a leaf of each hand.

Limit switch microswitches on the KR310D

CAME fits opening and closing limit switch microswitches to the KR310D. They tell the board when the leaf has reached each end, so the motor stops without relying on a timer. Our other CAME KRONO page, the KR300D, has no limit switch microswitch, so this is the version to choose if you want the end positions set by the motor itself.

The gearmotor is also irreversible, so the leaf stays shut when the motor stops. A tall, solid or wind exposed leaf may still benefit from an electric lock, and we confirm that at the survey. CAME lists a lock cylinder with a DIN key, code 001KR001, as an unlocking accessory.

240 W, 22 seconds and 16 cycles an hour on the CAME KRONO KR310D

The motor runs from a 230V, 50 or 60 Hz supply, drawing 240 W and 1.1 A. The thrust is listed as 400 to 3000 N, a range that the control board sets for your gate. The opening time to 90 degrees is 22 seconds, and the duty is 16 cycles an hour, about one full open and close every four minutes.

Pillar depth, hinge position and opening angle for the KRONO

An arm mounted motor needs clear depth from the hinge to the inside face of the pillar, so the arm can travel through its stroke. CAME’s dimension and opening angle tables are not clear in the data we have, so we cannot check your pillars against a number from the page. We measure on site and ask CAME for the figures.

Send photos of both pillars with a tape across the depth, and we confirm the fit before you order.

CAME KRONO KR310D, KR300D or KR510D: which version do you need

CAME sells the KRONO in several versions, and we list more than one. The table shows only what CAME and its sellers publish.

Choose the KR310D for a standard 3 m leaf with end of travel microswitches. Choose the KR510D if your leaf is longer. Ask us to compare them for your gate.

CAME control panel, CONNECT and safety for the KR310D

CAME suggests the 002ZA3P control panel for the KRONO. It also describes CONNECT remote control through a gateway or the CAME KEY, a CXN BUS two wire connection and a snap in card slot for the RIO System 2.0. We confirm the panel for your gate.

The supplier’s kit includes the CAME TOP432EE remotes and Bluebus photocells. A CAME receiver pairs only with CAME handsets, so Somfy, BFT and Nice remotes cannot pair with it. Photocells stop the gate closing on a car or a person, and a flashing light warns people before it moves. A safety edge is worth adding where a leaf closes toward a wall or a footpath.

230V only: the CAME KRONO KR310D and power cuts

CAME lists this motor as a 230V gearmotor only. It runs on mains power, and a power cut leaves the leaf where it stopped, held by the irreversible gearmotor. We release it with the manual release and keep the key where you can reach it. If a battery backup matters to you, ask us, and we point you to a 24V swing motor.

IP54, heat and sand: the CAME KRONO KR310D in Oman

IP54 protects against dust and splashing water, which is a better rating than IP44 on some other swing kits. The motor works from minus 20 to plus 55°C, and has thermal protection at 150°C. We mount it clear of standing water, in shade where we can, and we seal the cable entries. Coastal sites in Sohar, Sur and Salalah add salt, which attacks pivots first, so keep the hinges greased.

What CAME does not state, and what we confirm

CAME KRONO KR310D specification

CAME swing gate motor Muscat: supply and fitting across Oman

We are a physical shop in Al Khuwair, Muscat with our own engineers. They fit, programme and service CAME swing gate motors across all eleven governorates: Muscat, Al Batinah North, Al Batinah South, Ad Dakhiliyah, Ash Sharqiyah North, Ash Sharqiyah South, Adh Dhahirah, Al Buraimi, Al Wusta, Dhofar and Musandam. That reaches Sohar in Al Batinah North, Nizwa in Ad Dakhiliyah, Sur in Ash Sharqiyah South, Salalah in Dhofar and Duqm in Al Wusta.

Visit us at Shop No 176, Way Street No 57, Block No 17/2, Al Khuwair, Muscat, Oman. Call or WhatsApp +968 78109286, or email contact@doorsauto.com. See all CAME swing gate motors, send your pillar photos through the contact page, or visit the Doors Auto shop.

CAME KRONO KR310D FAQ

What is the CAME KRONO KR310D?

An irreversible right hand 230V swing gate motor with limit switch microswitches, for leaves up to 3 m and 400 kg, with a 22 second opening and an IP54 rating.

What is the difference between the KR310D and the KR310S?

The D is the right hand motor and the S is the left hand motor, with the same specification. A double gate usually needs one of each, and we confirm at the survey.

What is the difference between the CAME KR310D and the KR300D?

The KR310D has opening and closing limit switch microswitches, and the KR300D does not. The two share the same leaf limits, power and opening time.

How long a gate leaf can the CAME KRONO KR310D move?

CAME pairs 3 m with 400 kg, 2.5 m with 600 kg and 2 m with 800 kg. For leaves up to 5 m, we suggest the KR510 version.

What is the CAME KRONO KR310D price in Oman?

OMR 310.000, in stock at our Muscat shop. Installation is quoted separately once we have seen the gate.

Do you fit a CAME swing gate motor in Muscat and across Oman?

Yes. Our engineers fit and programme CAME swing gate motors in Muscat, Sohar, Nizwa, Sur, Salalah, Duqm and across all eleven governorates.
