CAME BK 2200 kg Sliding Gate Motor Oman, Heaviest BK Kit for Large Gates

Description

The CAME BK 2200 kg is the heaviest CAME sliding gate motor kit we list, for large gates up to 2,200 kg and up to 20 m long. The control board has a display, stores 250 users and runs self diagnosing safety devices. The kit comes with two remotes, a pair of Bluebus photocells, a receiver, a blinker light, a 4 metre nylon rack and a push button.

Two points come first. A gate this heavy needs a steel rack and a track built for the load, not the nylon rack in the kit. And the listing does not publish the power, the duty or the temperature range, so we confirm them before we quote.

CAME BK 2200 kg price in Oman and what is in the kit

Price: OMR 540.000, in stock at our Muscat shop. Installation is quoted separately once we have seen the gate.

• CAME BK 2200 motor
• Integrated control unit with a display
• Two remote controls
• One pair of Bluebus photocells
• One remote receiver
• One blinker light
• One 4 metre nylon rack
• One push button

Not included: a steel rack, the extra rack a long gate needs, a safety edge, a battery backup and the fixings for your base plate. We list what your gate needs in the quote.

2200 kg sliding gate motor in Oman: which CAME motor for which gate

Choose the motor by the weight of the moving leaf, with a margin. A motor that runs near its limit all day wears out early.

If your gate weighs close to a limit, step up to the next motor. A larger motor runs cooler and lasts longer on the same gate.

Steel rack for a heavy sliding gate: module 4 or 6

The kit includes a 4 metre nylon rack. CAME lists the pinion as module 4 and also as available in module 4 or 6, so the shipped module is not clear. The rack and the pinion must share a module, or they will not mesh.

Nylon rack is usually rated for much lighter gates than steel. At 2,200 kg we quote steel rack, and we confirm the module with the supplier first. The rack must also run along the full length of the leaf, so a gate listed up to 20 m needs a large run, joined in line and fixed straight.

Track, rollers and foundation for a 2200 kg gate

A motor does not carry the gate. The track, the rollers and the foundation do. A heavy gate on a weak track will wear out the rollers and strain the motor, whatever its rating. We check four things before we fit.

What the listing does not publish, and what we confirm

The listing gives no supply voltage, power, current, torque, speed, duty rating, IP rating, temperature range or dimensions. The sibling CAME BK 1800 kg publishes these, but we do not copy its figures to a bigger motor.

We get these from the supplier and the motor label, and give them to you in the quote.

CAME BK control board: display, 250 users and safety edges

The integrated board has terminal blocks and a display, and stores up to 250 users, which suits a block, a compound or a works yard. Its safety devices are self diagnosing, so a failed photocell does not leave the gate unprotected. The safety inputs can take 8k2 resistive safety edges, which we recommend on a heavy gate that closes toward a wall or a footpath.

The photocell pair in the kit is Bluebus, CAME’s own bus system. It suits CAME boards. Photocells from another brand are not assumed to connect.

Magnetic limit switches and the manual release

The unit is ready for magnetic limit switches, which are not listed as included. They have no mechanical contact to wear, so they are a good choice on a heavy gate. A manual release is essential on a gate this size. The listing gives no battery details, so we do not promise that the gate opens in a power cut.

CAME remote controls: receiver and what pairs

A remote receiver is in the kit, with two remotes. The listing does not state the radio frequency. A CAME receiver pairs only with CAME handsets. Somfy, BFT and Nice remotes cannot pair with it, because each brand uses its own coding.

Heat, sand and a heavy CAME gate motor in Oman

A heavy gate motor runs hot under load, and an Omani summer adds to it. We mount the motor in shade where possible, on a raised base clear of standing water and blown sand, and we leave room for air around the housing. Keep the track clean, because sand wears rollers and rack faster than any motor fault.

CAME BK 2200 kg specification

CAME heavy sliding gate motor Muscat: supply and fitting across Oman

We are a physical shop in Al Khuwair, Muscat with our own engineers. They fit, programme and service sliding gate motors across all eleven governorates: Muscat, Al Batinah North, Al Batinah South, Ad Dakhiliyah, Ash Sharqiyah North, Ash Sharqiyah South, Adh Dhahirah, Al Buraimi, Al Wusta, Dhofar and Musandam. That reaches Sohar in Al Batinah North, Nizwa in Ad Dakhiliyah, Sur in Ash Sharqiyah South, Salalah in Dhofar and Duqm in Al Wusta.

Visit us at Shop No 176, Way Street No 57, Block No 17/2, Al Khuwair, Muscat, Oman. Call or WhatsApp +968 78109286, or email contact@doorsauto.com. Send the weight, the length and a photo of your gate through the contact page. Compare more in our sliding gate opener range, or visit the Doors Auto shop.

CAME BK 2200 kg FAQ

What is the CAME BK 2200 kg?

The heaviest CAME sliding gate motor kit we list, for large gates up to 2,200 kg and up to 20 m long, with a control board that stores 250 users.

Does the CAME BK 2200 kg need a steel rack?

Yes, for a gate near its limit. The kit includes a 4 metre nylon rack, so we confirm the module and quote steel rack for heavy gates.

Should I choose the CAME BK 2200 kg or the BK 1800 kg?

Choose by the weight of the leaf, with a margin. If your gate is near 1800 kg, step up to the 2200 kg, because a larger motor runs cooler and lasts longer.

Will my Somfy or BFT remote work with the CAME BK 2200 kg?

No. A CAME receiver pairs only with CAME handsets, because each brand uses its own coding. You need CAME remotes.

What is the CAME BK 2200 kg price in Oman?

OMR 540.000, in stock at our Muscat shop. Installation is quoted separately once we have seen the gate.

Do you fit a CAME heavy sliding gate motor in Muscat and across Oman?

Yes. Our engineers fit and programme CAME motors in Muscat, Sohar, Nizwa, Sur, Salalah, Duqm and across all eleven governorates.
