CAME BKS22TLS 2200 kg Sliding Gate Motor Oman, 400V Heavy Duty with ZT6 Panel

Description

The CAME BKS22TLS is a heavy duty commercial sliding gate motor for gates up to 2200 kg and up to 18 m long. It has a 400 V, 600 W motor, a 50% duty rating, mechanical limit switches and a ZT6 control panel housed in a separate protected case. It carries an IP54 rating and works from minus 20 to plus 55°C.

Two points come first. A 400 V motor needs a three phase supply, so we check your site before you buy. And the listing does not say whether the control panel, the rack or the photocells are in the price, so we quote each item line by line.

CAME BKS22TLS model code and CAME code

The supplier lists the model as BKS22TLS, with CAME code 801MS-0131. We read the code on the motor label when you collect it, so you know exactly which unit you have.

CAME BKS22TLS price in Oman and what we quote with it

Price: OMR 632.000, in stock at our Muscat shop. Installation is quoted separately once we have seen the site.

The listing does not state the box contents, so we do not call this a kit. Before you pay, we confirm what the price covers, and we list every extra your gate needs.

CAME BKS22TLS or CAME BK 2200 kg: which 2200 kg motor

We list two CAME motors rated for 2200 kg, and they are built differently. The table shows only what each listing publishes.

The BK 2200 kg is a ready kit at a lower price. The BKS22TLS publishes its supply, its duty and its temperature range, and its panel is separate and protected, which suits a commercial site. Ask us to compare them for your gate and your supply.

400 V sliding gate motor: what your site needs

The motor is listed at 400 V and 600 W. A 400 V motor normally runs from a three phase supply, which many houses do not have, though many factories, depots and farms do. The listing gives no single phase option. We confirm the exact supply with CAME, so your electrician installs the right cable and protection.

175 mm per second, 240 mm per second and the BK25PIN

The standard speed is 175 millimetres a second, which is about 10.5 metres a minute, so a gate that opens 6 metres takes about 34 seconds. CAME lists a faster speed of 240 millimetres a second with an accessory called BK25PIN, which cuts the same stroke to about 25 seconds.

The listing does not describe the BK25PIN, so we confirm what it is, what it costs and what it needs before we quote the faster speed. A faster gate needs stronger safety devices, so we plan that together.

50% duty and the ZT6 control panel

CAME lists a 50% duty rating. The motor can run for about half the time, in cycles with rest between. The control is a ZT6 intelligent panel in a separate protected case, mounted away from the motor and from the heat of the housing.

Obstacle detection, pedestrian opening and mechanical limit switches

The BKS22TLS stops and reverses when it meets an obstacle, and it offers a pedestrian opening, a partial stroke so that a person can walk through without opening the full leaf. The limit switches are mechanical, so we set the end points by hand during installation, and test them before we leave.

On a gate this heavy we also fit photocells and safety edges. The type must match the ZT6 panel, so we do not guess.

Steel rack and track for a 2200 kg gate

The listing does not state the pinion module or the rack. At this weight we quote steel rack, and we confirm the module with CAME first. The rack and the pinion must share a module, or they will not mesh. A gate listed up to 18 m needs a large run, joined in line and fixed straight.

A motor does not carry the gate. The frame, the track, the rollers and the foundation do. We check four things before we fit.

CAME remote controls and access control

The listing does not state the radio frequency, a receiver or the remote memory. A CAME receiver pairs only with CAME handsets. Somfy, BFT and Nice remotes cannot pair with it, because each brand uses its own coding. A commercial site often wants a keypad, a card reader or an intercom, and we plan that with you at the survey.

IP54, minus 20 to plus 55°C: the CAME BKS22TLS in Oman

IP54 protects against dust and splashing water, and the motor is listed to plus 55°C, which covers most Omani summers when it sits in shade. We mount it on a raised base clear of standing water and blown sand, and we keep the ZT6 panel out of direct sun. Keep the track clean, because sand wears rollers and rack faster than any motor fault.

CAME BKS22TLS specification

CAME commercial sliding gate motor Muscat: supply and fitting across Oman

We are a physical shop in Al Khuwair, Muscat with our own engineers. They fit, programme and service sliding gate motors across all eleven governorates: Muscat, Al Batinah North, Al Batinah South, Ad Dakhiliyah, Ash Sharqiyah North, Ash Sharqiyah South, Adh Dhahirah, Al Buraimi, Al Wusta, Dhofar and Musandam. That reaches Sohar in Al Batinah North, Nizwa in Ad Dakhiliyah, Sur in Ash Sharqiyah South, Salalah in Dhofar and Duqm in Al Wusta.

Visit us at Shop No 176, Way Street No 57, Block No 17/2, Al Khuwair, Muscat, Oman. Call or WhatsApp +968 78109286, or email contact@doorsauto.com. Send the weight, the length, the supply and a photo of your gate through the contact page. Compare more in our sliding gate opener range, or visit the Doors Auto shop.

CAME BKS22TLS FAQ

What is the CAME BKS22TLS?

A heavy duty commercial sliding gate motor for gates up to 2200 kg and 18 m long, with a 400 V, 600 W motor, a 50% duty rating and a ZT6 control panel in a separate case.

Does the CAME BKS22TLS need a three phase supply?

It is listed as a 400 V motor, which normally needs a three phase supply. We confirm the exact voltage with CAME, and your electrician sizes the cable and the protection.

What is the difference between the CAME BKS22TLS and the BK 2200 kg?

The BKS22TLS is a 400 V motor with a separate ZT6 panel and an 18 m limit. The BK 2200 kg is a kit with an integrated board and a 20 m limit. We compare them for your gate.

Will my Somfy or BFT remote work with the CAME BKS22TLS?

No. A CAME receiver pairs only with CAME handsets, because each brand uses its own coding. You need CAME remotes.

What is the CAME BKS22TLS price in Oman?

OMR 632.000, in stock at our Muscat shop. Installation is quoted separately once we have seen the site.

Do you fit a CAME commercial sliding gate motor in Muscat and across Oman?

Yes. Our engineers fit and programme CAME motors in Muscat, Sohar, Nizwa, Sur, Salalah, Duqm and across all eleven governorates.
